About Flake Graphite

It is called Flake Graphite because of the form which Graphite exists.  This Graphite is disseminated throughout the rock or clay in the form like salt-and-pepper.  The grade of these raw ore is low, usually FC2-10%, most of which is mined by open-pit.  The Mined Graphite is crushed with a wet ball mill to separate rocks and Graphite, and floating beneficiation is performed that only Graphite is floated to be recovered repeatedly, then the Graphite reached to FC80-97% is imported to Japan.  Graphite of large flake is often used in refractory applications, and the others are used for various applications after crushed and classified in Japan.

•

•

•

•

About Vein Graphite

It is called Vein Graphite.  It is mined by underground method, exists in the form of lumps between the bedrocks, and the grade of raw ore is generally high at FC60-98%.  It is removed impurities by hand sorting, crushed, and classified by grain-size.  Depending on the shape, it can be classified into “Lamps” which is average of about 25 mm, “Chips” which is a wood chip size, and “Chippy dust” which is powder mixing.  Compared to Flake Graphite, impurities are often present alone, and high grade can be obtained by only flotation.  Although its fire resistance is slightly inferior to that of Flake Graphite, it has same lubrication and electrical properties and it is widely used.  Regarding how to use it with Flake Graphite, at the moment, every user has own methods and various evaluations.

•

•

•

•

Main Applications

List of Flake Graphite

Product Name	FC (Fixed Carbon)	ASH	VM (Volatile Matter)	MO (Moisture)	Granularity (Opening)	Average Particle Diameter (μm)
FT-2	99.9% or more	0.1% or less	–	1% or less	–	2
FT-4	99.9% or more	0.1% or less	–	1% or less	–	4
FT-4J	99.9% or more	0.1% or less	–	1% or less	–	4
FT-7J	99.9% or more	0.1% or less	–	1% or less	–	7
MF-10N	99% or more	1% or less	–	1% or less	–	10
MF-20N	99% or more	1% or less	–	1% or less	–	20
SC-120	82% or more	15% or less	3% or less	1% or less	–	50-75
DO-60F	92% or more	6% or less	2% or less	1% or less	-180μm:80% or less	–
CRC-80N	99% or more	0.5% or less	0.5% or less	1% or less	+180μm:80% or more	–
ACG-30J	98% or more	1% or less	1% or less	1% or less	–	30
ACG-45J	98% or more	1% or less	1% or less	1% or less	–	45
ACG-PS	94% or more	6% or less	1.5% or less	1% or less	-150μm:60% or more	–
ACG-100I	94% or more	5% or less	1% or less	1% or less	-150μm:80% or more	–
ACG-80L98	98% or more	1.5% or less	0.5% or less	1% or less	+180μm:80% or more	–
ACG-50L98	98% or more	1.5% or less	0.5% or less	1% or less	+300μm:80% or more	–

List of Ultra-High Purity Flake Graphite

Product Name	FC (Fixed Carbon)	ASH	Ash Composition	MO (Moisture)	SIO2	Particle Size Distribution (μm)
FT-2SP	99.9% or more	0.1% or less	Al203:0.005%	1% or less	0.0036%	Average particle size: 2

List of Vein Graphite

Product Name	FC (Fixed Carbon)	ASH	VM (Volatile Matter)	MO (Moisture)	Granularity (Opening)	Average Particle Diameter (μm)
BV-150	93% or more	5% or less	2% or less	1% or less	-100μｍ:80% or more	–
BV-100	93% or more	5% or less	2% or less	1% or less	-150μｍ:80% or less	–
KV-150	98% or more	0.5% or less	0.5% or less	1% or less	-100μｍ:80% or more	–
KV-100	98% or more	0.5% or less	0.5% or less	1% or less	-150μｍ:80% or less	–
SV-100	98% or more	0.5% or less	0.5% or less	1% or less	-150μｍ:80% or less	–
SV-150	98% or more	0.5% or less	0.5% or less	1% or less	-100μｍ:80% or more	–
SV-40J	98% or more	0.5% or less	0.5% or less	1% or less	–	40
SV-20J	98% or more	0.5% or less	0.5% or less	1% or less	–	20
SV-10J	98% or more	0.5% or less	0.5% or less	1% or less	–	10
SV-40JC	98% or more	0.5% or less	0.5% or less	1% or less	–	40
SV-20JC	98% or more	0.5% or less	0.5% or less	1% or less	–	20
SV-10JC	98% or more	0.5% or less	0.5% or less	1% or less	–	10
